Characteristics
Rated input power 850 W
Output power 490 W
Maximum torque 36 / 14 Nm
Drill-¯ masonry 20 mm
Drill-¯ concrete 18 mm
Drill ¯ steel 13 / 8 mm
Drill-¯ soft wood 40 / 25 mm
No-load speed 0 - 1100 / 0 - 3100 rpm
Revolutions at rated load 640 / 1800 rpm
Maximum impact rate 58900 bpm
Gears 2
Chuck capacity 1.5 - 13 mm
Collar diameter 43 mm
Drill spindle with hexagonal recess 6.35 mm
Drill spindle thread 1/2 " - 20 UNF
Chuck clamping type Quick-action Keyless Chuck
Weight (without power cable) 2.6 kg
Vibration
Drilling in metal 4.2 m/s_
Uncertainty of measurement K 1.5 m/s_
Impact drilling concrete 17 m/s_
Uncertainty of measurement K 1.5 m/s_
Noise emission
Sound pressure level 103 dB(A)
Sound power level (LwA) 114 dB(A)
Uncertainty of measurement K 3 dB(A)
